SMOOV
by alber

SMOOV was developed by a team of entrepreneurs, operating as a separate start-up, within Alber Gmbh, world leaders in power assist and power add on devices for wheelchairs.

The result is a product boasting start-up levels of innovation, but the quality and execution of a manufacturing pro.

navigate smoov

smoov drive unit

- Unobtrusive, high-quality design
- Robust, rustproof housing and rustproof fork
- Integrated lithium ion battery pack for a range up to 20 km
- High-performance drive for a maximum speed of up to 6 km/h,
optionally of up to 6 km/h or 10 km/h with the upgrade via the Mobility app
- On/Off button and remaining capacity and operating mode display
- Ergonomic carrying handle
- Magnetic charger socket
- USB-C socket to charge the control unit or a smartphone

smoov control unit

- Large, ergonomic speed selection and On/Off knob
- Integrated LED display for operating status and remaining capacity of drive unit and control unit
- Integrated lithium ion battery cell for an operating time of approx. 20 hours

smoov charger

- Handy, compact charger
- Automatic charging and switch-off mechanism
- Multi-range charger 100-240 V, 50-60 Hz
- Charging time of an empty battery approx. 6 hours

wheelchair instillation kit

- Mechanical connection of the SMOOV one to the manual active wheelchair
- Can be mounted on most active wheelchairs with a fixed crossbar / camber tube (rigid-frame wheelchairs)
- Consists of a crossbar/camber tube bracket set and control unit bracket set

smoov app - free

Cockpit Controls:

• drive mode selection (eco, tour, sport, custom)

• smoov battery level indicator

• control unit battery level indicator

• on/off button for rear light

Tour Metrics:

• track you journey

• time, distance, average speed, max speed

Settings adjustment:

• adjust settings for each drive mode

  • max speeds

  • max torque

  • speed adjustment amount for each control wheel turn

Diagnostics:

• reads error codes and explains problem

• indicates steps to take to correct problem

• links to service contact

Navigation (paid feature)

Auto Speed (future feature)

smoov numbers

Drive unit

• Dimensions Length: 385 mm
  Width: 145 mm
  Height: 340 mm

• Weight 7,2 kg

• Color Black

• Connectivity Bluetooth

• Battery Lithium-Ion. 224 Wh

• Drive output 250 W nominal, 450 W peak

• Range Up to 20 km

• Max user weight 140 kg

• maximum speed 0- 10 km/h

smoov mounting

easy come. easy go

You can easily and at any time dock and undock your SMOOV one thanks to the releasing device and carrying handle. Even whilst you are sitting in the wheelchair. Instillation is quick and easy.

smoov full specs

General

Weight of the person Max: 140kg
Permissible total weight Max: 170kg
Climbing capability: up to 16%

 Drive unit

Motor power rating: 250W
Max. motor power: 450W
Operating voltage: 36V
Speed: 0-10 km/h

Battery pack (drive unit)

Battery cells: 36 V; 6.2 Ah
-Lithium ion cells, leakproof and maintenance-free, 24 months guarantee

Battery power: 224 Wh
-Safe for air transportation according to IATA

Range: Up to 20 km
-depending on the surface, user weight, temperature and terrain

Battery charger

Input voltage: 100-240v
Frequency range: 50-60 Hz
Output voltage: 48 V (DC)
Charging current: 1 A
Charging time: Approx 6 hours

Weight

Drive unit: 7.2 kg
Control unit: 250 g
Battery charger: 500 g
Control unit bracket: Approx. 100 g
Crossbar/camber tube bracket: Approx. 230 g
